Creating a Custom Stepper Form in Android

When creating forms in Android apps, you may want to present all the information in the available screen space. This approach is a bit cumbersome as not everything can fit in one screen. <!--more--> To improve consistency, the user interface, and make the app more interactive, a stepper is implemented.

Prerequisites #

To follow along:

• Make sure you have Android Studio installed.
• You need a good understanding of how to create and run Android applications.
• Knowledge of the Kotlin programming language and ViewBinding is required.

Table of contents #

• Prerequisites
• Table of contents
• Goals
• Introduction
• Application of Stepper forms
• Step 1 - Creating an Android project
• Step 2 - Setting up the project
• Step 3 - Define step titles
• Step 4 - App layout
  • Define StepView
  • Explanation
• Define form layouts
  • Personal details form
  • Location details form
  • Usage details form
  • Employment details form
  • Loan details form
  • Navigation button
• Step 5 - Navigating to the next step
  • Explanation
• Step 6 - Handling back navigation
  • Explanation
• Conclusion

Goals #

By the end of this tutorial, the reader will be able to:

• Understand what a stepper form is.
• Know various applications of stepper forms.
• Learn how to create a stepper form.

Introduction #

Steppers display progress through a sequence of logical and numbered steps. They may also be used for navigation and displaying transient feedback message when a step is saved.

Stepper divides the current screen into different views and the contents are distributed over all of them. Users can navigate through these views.

Steppers keep users informed about their progress by indicating what step they’re on and how many steps they have left. This could otherwise be a challenge due to the limited screen space.

Application of Stepper forms #

Stepper Forms can be used in:

• Loan apps whereby a user needs to fill in a lot of details.
• Applications where when a user is registering, they need to fill in more information that cannot fit on a single screen.

In this tutorial, we will create a form for a loan application that asks the user to fill in details such as names, location details, how he/she will use the loan, current employment details, and finally, the loan amount in the last form.

Step 1 - Creating an Android project #

Launch Android Studio and create an empty android project.

Step 2 - Setting up the project #

In this step, copy the following dependency and paste it into your app-level build.gradle file.

dependencies {
    implementation 'com.shuhart.stepview:stepview:1.5.1'
}

Step 3 - Define step titles #

In the res directory, open string.xml and add the following array. This is the list of titles that will appear at the top of each step.

<array name="details">
    <item>Personal</item>
    <item>Location</item>
    <item>Usage</item>
    <item>Employment</item>
    <item>Loan</item>
</array>

Step 4 - App layout #

At this point, we are going to define a layout that will define how the different steps will be displayed.

Define StepView #

In the res directory, open your layout file and add the following code.

    <com.shuhart.stepview.StepView
    android:id="@+id/step_view"
    android:layout_width="0dp"
    android:layout_height="wrap_content"
    android:layout_gravity="center"
    android:layout_marginStart="8dp"
    android:layout_marginTop="16dp"
    android:layout_marginEnd="8dp"
    android:padding="8dp"
    app:sv_animationDuration="1"
    app:sv_animationType="Line"
    app:sv_doneCircleColor="@color/primaryLightColor"
    app:sv_doneCircleRadius="20dp"
    app:sv_doneStepLineColor="@color/primaryLightColor"
    app:sv_doneStepMarkColor="@android:color/black"
    app:sv_doneTextColor="@android:color/darker_gray"
    app:sv_nextStepLineColor="@color/colorGray"
    app:sv_nextTextColor="@color/colorGray"
    app:sv_selectedCircleColor="@color/primaryDarkColor"
    app:sv_selectedCircleRadius="12dp"
    app:sv_selectedStepNumberColor="@color/colorLightGrayMore"
    app:sv_selectedTextColor="@color/primaryDarkColor"
    app:sv_stepLineWidth="1dp"
    app:sv_stepNumberTextSize="12sp"
    app:sv_stepPadding="4dp"
    app:sv_stepViewStyle="@style/StepView"
    app:sv_steps="@array/details"
    app:sv_stepsNumber="3"
    app:sv_textSize="12sp"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintHorizontal_bias="0.5"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toTopOf="parent"/>

Explanation #

In this View:

• We have added the attribute app:sv_steps="@array/details" that contains the steps that we defined in strings.

You can play around with the different attributes available to come up with a stepper of your preferred appearance. I.e changing the different color and size properties.

Define form layouts #

To achieve the different forms in different steps, we will create layouts and hide them, then displaying them at the right step.

We will also define a Button at the bottom of the layout. This button will be used to navigate from one form to another.

Personal details form #

The following will be the layout for this step:

<androidx.constraintlayout.widget.ConstraintLayout
    android:id="@+id/personal_details"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:visibility="visible"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintHorizontal_bias="1.0"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toBottomOf="@+id/step_view">

<!--  YOUR_VIEWS -->

</androidx.constraintlayout.widget.ConstraintLayout>

Location details form #

<androidx.constraintlayout.widget.ConstraintLayout
    android:id="@+id/location"
    android:layout_width="match_parent"
    android:layout_height="530dp"
    android:visibility="gone"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintHorizontal_bias="1.0"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toBottomOf="@+id/step_view">

    <!-- YOUR_VIEWS -->

</androidx.constraintlayout.widget.ConstraintLayout>

Usage details form #

<androidx.constraintlayout.widget.ConstraintLayout
    android:id="@+id/usage"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:visibility="gone"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintHorizontal_bias="0.0"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toBottomOf="@+id/step_view">

    <!-- YOUR_VIEWS -->

</androidx.constraintlayout.widget.ConstraintLayout>

Employment details form #

<androidx.constraintlayout.widget.ConstraintLayout
    android:id="@+id/employment"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:visibility="gone"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintHorizontal_bias="0.0"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toBottomOf="@+id/step_view">

    <!-- YOUR_VIEWS -->

</androidx.constraintlayout.widget.ConstraintLayout>

Loan details form #

<androidx.constraintlayout.widget.ConstraintLayout
    android:id="@+id/repayment"
    android:layout_width="match_parent"
    android:layout_height="600dp"
    android:visibility="gone"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintHorizontal_bias="0.0"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toBottomOf="@+id/step_view">

    <!-- YOUR_VIEWS -->

</androidx.constraintlayout.widget.ConstraintLayout>

Navigation button #

Finally, lets add a button that will help us in navigating through the five forms.

<com.google.android.material.button.MaterialButton
    android:id="@+id/button"
    android:layout_width="0dp"
    android:layout_height="wrap_content"
    android:layout_marginStart="16dp"
    android:layout_marginEnd="16dp"
    android:layout_marginBottom="64dp"
    android:padding="12dp"
    android:text="Next"
    app:layout_constraintBottom_toBottomOf="parent"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintStart_toStartOf="parent" />

NOTE: Except for the first form, set the other forms' visibility to gone. This will ensure that only one form is visible at a time.

Step 5 - Navigating to the next step #

After defining our layouts, what remains is to add some logic to our MainActivity.kt to help us navigate through different forms.

Define a variable that will hold the position of each form:

private var position = 0

Also, to make sure that our StepView always starts at step one, inside onCreate method, add this line of code:

binding.stepView.done(false)

Next, we need to add a ClickListener to the Next Button to display and hide the respective form(s) based on the position.

binding.button.setOnClickListener {
    when (position) {
        0 -> {
            binding.personalDetails.visibility = View.GONE
            binding.location.visibility = View.VISIBLE
            position = 1
            binding.stepView.done(false)
            binding.stepView.go(position, true)
            binding.button.text = "Next"
        }
        1 -> {
            binding.location.visibility = View.GONE
            binding.usage.visibility = View.VISIBLE
            position = 2
            binding.stepView.done(false)
            binding.stepView.go(position, true)
        }
        2 -> {
            binding.usage.visibility = View.GONE
            binding.employment.visibility = View.VISIBLE
            position = 3
            binding.stepView.done(false)
            binding.stepView.go(position, true)
        }
        3 -> {
            binding.employment.visibility = View.GONE
            binding.repayment.visibility = View.VISIBLE
            position = 4
            binding.stepView.done(false)
            binding.stepView.go(position, true)
            binding.button.text = "Submit"
        }

        else -> {
            position = 0
            binding.stepView.done(true)
            binding.stepView.go(it, true)

            // Go to another Activity or Fragment
        }
    }
}

Explanation #

Inside the onClickListener of the button, we are switching positions, whereby, for each position:

• We hide the current layout/form and make the next one visible.
• We increment the position to the corresponding layout.
• We make sure the binding.stepView.done is false so that the StepView will show the current step as not done, except for the last step.
• We then make the StepView go to the incremented position - binding.stepView.go(position, true).
• Finally, for the first three layouts, we change the Button text to "Next". In the fourth step, we change the text to "Submit".

In the else part, we set the position to "0" and call the StepView's done method.

In this else clause, we can add code to either navigate a user to another Activity or Fragment

Step 6 - Handling back navigation #

It is good to add a feature that allows a user to navigate to the previous step. To do so, we will implement the onBackPressed method.

override fun onBackPressed() {
    when (position) {
        0 -> {
            // exit the app
            super.onBackPressed()
        }

        1 -> {
            binding.location.visibility = View.GONE
            binding.personalDetails.visibility = View.VISIBLE
            position = 0
            binding.stepView.done(false)
            binding.stepView.go(position, true)
            binding.button.text = "Next"
        }
        2 -> {
            binding.usage.visibility = View.GONE
            binding.location.visibility = View.VISIBLE
            position = 1
            binding.stepView.done(false)
            binding.stepView.go(position, true)
        }
        3 -> {
            binding.employment.visibility = View.GONE
            binding.usage.visibility = View.VISIBLE
            position = 2
            binding.stepView.done(false)
            binding.stepView.go(position, true)
        }
        else -> {
            binding.repayment.visibility = View.GONE
            binding.employment.visibility = View.VISIBLE
            position = 3
            binding.stepView.done(false)
            binding.stepView.go(position, true)
            binding.button.text = "Next"
        }
    }
}

Explanation #

onBackPressed:

• If the position is "0" the app exits.
• For the other positions, we hide the current layout and make the preceding layout visible together with its position.

That's all, you have created a customizable Stepper form.

Conclusion #

In this tutorial, we have learned what a stepper is, what are its applications, and how to create a stepper form using StepView. Go ahead and use this awesome feature in your apps.

For a full implementation of the Stepper form, check out this Github repository.

Happy coding!

---
